MTP10-A6F55D
Digital lnfrared Temperature Sensor
New
Digital lnfrared Temperature Sensor
#All products
#Sensors
#Infrared thermopile temperature sensor
Digital lnfrared Temperature Sensor
The MTP10-A6F55D is a single-channel digital infrared temperature thermopile sensor that facilitates integration into non-contact temperature measurement applications. The sensor is packaged in a small TO39 and integrates a thermopile temperature sensor, PGA , A/D, DSP, MUX and communication protocol. The MTP10-A6F55D is factory calibrated in a wide range, and can work normally in the environment of -20℃~85℃, and measure the temperature of objects in the range of -20℃~300℃.
Self-calibration
Automatic temperature compensation
High measurement accuracy
Multiple viewing angles and test distances available
Low cost
Technology type
thermopile
Package type
TO-39
Output Type
Digital Output
Property
Tobj measurement accuracy
±2°C/±2%*Tobj
Filter type
Long wave communication
Filter passes through the wavelength range
5.5~14μm
Average transmittance of filter
≥80% 5.5~14μm
Average cut-off rate of filter
1%<5μm
Supply voltage
2.4V~3.6V type:3.3V
Power supply current
Continuous mode: 600 μA; Sleep mode: 5.0 μA
Temperature range
-20~300℃
Resolving power
0.1℃
Field
62°
Environment
Work environment
-20~85℃
Storage environment
-40~100℃
